Depth Required

Minimum Depth for Installation:

• Inside Mount: 3/4" Window Depth
• Outside Mount: 1-1/2" Bracket Height

Headrail Depth for Flush Mount:

• Cordless: 2-1/2"
• Top Down Bottom Up: 2-1/2"
• Cord Loop: 3-1/2"
• Motorization: 3-1/2"
• Movable Liner (Dual) Shades: 4-3/8"

Size Limitations by Control Type

Cordless

• Minimum Width: 18"
• Maximum Width: 96"
• Minimum Height: 18"
• Maximum Width: 96"

Top Down Bottom Up

• Minimum Width: 20"
• Maximum Width: 60"
• Minimum Height: 18"
• Maximum Width: 84"

Cord Loop

• Minimum Width: 18"
• Maximum Width: 96"
• Minimum Height: 18"
• Maximum Width: 108"

Motorized

• Minimum Width: 23"
• Maximum Width: 96"
• Minimum Height: 18"
• Maximum Width: 108"

Further Customization Available

• Liner color: default is color coordinating
• Edge binding color: default is color coordinating
• Hold down brackets and spacer blocks are available upon request
• Cut outs (for wainscoting, door handles)
• Multiple shades on one head rail (common valance)
• Custom valance height (standard is 6")
• Custom valance return height (standard is 1.5" shorter than the valance)
• Cord position: default is right side
• Motor position: default is right side
• Cord loop length: default is 2/3 of shade height
• Cord loop material: default is color coordinated plastic. Nickel-plated is available

Motorization Details

• The number of remotes, wall switches, and chargers will depend on the number of shades, but can be adjusted upon request.
• Multi-channel remotes have 15 channels. Each channel can control up to 20 shades.
• Smart hubs have a range of 100'. For homes with multiple floors, one hub per floor is recommended.

Installation Guide

Motorization Guide

Smart Home Hub Guide

Production Lead Time: 2.5 to 4 Weeks.

Ships via UPS express from overseas.

Courtesy rush may be requested but is not guaranteed.
